Clean Room MIni Pleated replacement filter Hepa Filter for FFU with CE UL HV fiberglass H14

Short Description:

1. Mini-pleat design, low resistance, operational cost saving 2. Wide application,space-saving 3. Ultra-thin design, installation space-saving 4. Efficiency:99.95%@MPPS(H13), 99.995%@MPPS(H14) 5. Mini pleat of fiberglass media with lowest resistance 6. Individually tested for certificated leak proof 7. Gel seal design 8. Hotmelt separators 9. Lightweight and compact 10. Unique construction 11. Energy saving design

Price：: USD9-99/Piece

MOQ:: 10

Supply Ability:: 2000 Piece/Pieces per DayPackaging & Delivery

Payment:: L/C D/A T/T Western Union MoneyGram

Port：: TianJin ShangHai NingBo QingDao GuangZhou

Send email to us Download as PDF

Product Detail

Applications: Applicable to clean room and other area with stringent clean air requirements

Applicable conditions: Working temperature(ºC) ≤ 70(158ºF)

Features

1. Mini-pleat design, low resistance, operational cost saving

2. Wide application,space-saving

3. Ultra-thin design, installation space-saving

4. Efficiency:99.95%@MPPS(H13), 99.995%@MPPS(H14)

5. Mini pleat of fiberglass media with lowest resistance

6. Individually tested for certificated leak proof

7. Gel seal design

8. Hotmelt separators

9. Lightweight and compact

10. Unique construction

11. Energy saving design

Product Details
Type: Mini-pleat HEPA filter

Gasket: CR,EVA,EPDM,PU

Frame: Extruded aluminum.

Face guard: Baking finish

Separator: Hot-melt beads.

Filter class(EN1822):H12, H13,H14

Media: H&V Glass fiber, PTFE Recommended final pressure drop.: 500 Pa

Temperature / Humidity: 70°C / 100% RH

Packaging Delivery & Details

Industrial HEPA Air Filter one piece in poly bag to be put in one box, 100 boxes to be packed in one carton, Or as per customer’s packing instruction.

Port: Tianjin,Shanghai,Ningbo,Guangzhou,Qingdao

We not only produce all kinds of different normal size Mini-pleat HEPA filter, but also accept all kinds of customized size Mini-pleat HEPA filter.Please choose what size you want to buy refer to the below table,

Model Dimensions (W×H×D) mm	Filter grade EN1822	Airflow / pressure drop m³/h / Pa (± 15%)	Unit volume m³
610x610x50	H13	603/130	0.041
1170X1170X50	H13	2218/125	0.082
1170x570x50	H13	1080/130	0.073
610x610x70	H13	603/110	0.026
1170X1170X70	H13	2218/105	0.052
1170x570x70	H13	1080/110	0.046
610x610x90	H13	603/85	0.033
1170X1170X90	H13	2218/80	0.066
1170x570x90	H13	1080/85	0.060
610x610x50	H14	603/140	0.041
1170X1170X50	H14	2218/135	0.082
1170x570x50	H14	1080/140	0.073
610x610x70	H14	603/120	0.026
1170X1170X70	H14	2218/115	0.052
1170x570x70	H14	1080/120	0.046
610x610x90	H14	603/95	0.033
1170X1170X90	H14	2218/90	0.066
1170x570x90	H14	1080/95	0.060
